IMPORTANT! Particular attention must be paid during the insertion of the region of
the Airbag (5) that protect the chest area to avoid twisting the narrower
region passing on the right shoulder. The obstruction of the canal could
compromise the correct inflation and therefore the protection of the Airbag
(5) in the chest area (see Figure 13).
Chest (C)
C2
C1
Peripheral
sensors
LS1
LS2
Left
Shoulder
LS3
(LS)
Back
Protector
Zip
Connections
Left Hip
(LH)
LH1
38 EN
Peripheral
sensors pockets
LS1
RS1
Hook-
C1 C2
and-loop
patch
RS1
RH1
Right
Shoulder
FRONT
(RS)
RS2
sensors pockets
LS3 RS2
LS2
Right Hip
(RH)
RH1
LH1
BACK
Figure 12
LS2
WARNING! Always check that all the connection clips are properly closed after
the reassembly of the Airbag (5) on the Base Layer (1).
LH1
Storage
When not in use, it is recommended that users store the System in its original packaging.
Peripheral
It may be stored flat provided that no heavy or sharp objects are placed on top of it. The
System can also be stored hung up on a hanger. The System should always be stored in a
cool, dry place, out of direct sunlight.
The battery of the System slowly self-discharges, even if the System is not turned on,
RS1 especially if the System is stored in a warm environment. It is thus recommended that even
whilst in storage, the System be periodically recharged (at least once every 18 months) to
prevent battery drainage and shortening of the battery life.
IMPORTANT!
RH1
CORRECT
Figure 13
If the battery becomes fully drained, the System may require a longer
time to recharge. It is thus recommended that the System be periodically
recharged as indicated.
INCORRECT
39 EN
