User guide
Switching motion sensor:
The motion sensor is off by default. Press the button "ON/OFF move" (5CP/6RC) to switch is on. The light indicator
"Status" under the button glows when the motion sensor is turned on. Press the button "ON/OFF move" once to
display the current setting.
Continuous ventilation mode
(24 Hours) The fan runs continuously on minimum speed until activated by the moisture sensor or an external switch.
Activation:
Press switch "6CP" on the control panel or "10RC" on the remote control.
This function is not available if the fan is connected as shown in wiring diagram 2.
Pause
PAUS E
This function can only be activated with the remote control.
If switch "7RC" is pressed, the fan will stop for 45 minutes or until switch "7RC" is pressed again.
Off/on
This function can only be activated with the remote control.
The fan can be turned off with switch "1RC". It will not then respond to signals
from the moisture sensor or external switches.
Interval ventilation stays on and the fan will extract for 2 hours after 15 hours.
Interval ventilation
Automatic function. Cannot be adjusted or turned off.
Starts every 15 hours and runs for 2 hours, extracting approx. 70 m³/h.
If the fan receives a signal from the moisture sensor or an external switch in this
period, it will be activated as normal.
Restoring factory settings
The integrated all-pole power switch is on the outside of the fan.
Turn the fan off using this switch. Press and hold in the "MODE" switch on the
fan's control panel and turn the fan on with the power switch at the same time.
When the fan starts, hold the "MODE" switch in for approx. 5 seconds until the
light below it stops flashing green.
