Controls
OSM Controls
The OSM controls on the front of the monitor provide the following
functions:
To access OSM press any of the control buttons ( , , , ) or the
PROCEED button.
To mute volume, press the RESET button.
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
NOTE: When RESET is pressed, a warning window will appear
allowing you to cancel the RESET function.
01c_english
Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves the highlighted
area left/right to select
control menus.
Has no function.
Resets the highlighted
control menu to the
factory setting.
English-8
8
Sub-Menu
Exits to the OSM main menu.
Moves the highlighted area
up/down to select one of the
controls.
Moves the bar left/right to
increase or decrease the
adjustment.
Activates Auto Adjust feature.
In Tool and Information Mode,
opens additional window.
Resets the highlighted control
to the factory setting.
