Installation
To attach the MultiSync LCD1525M monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. For PC: Connect the 15-pin mini D-SUB of the appropriate
signal cable to the connector for the display card in your system
(Figure A.1). Tighten all screws.
For Mac: Connect the MultiSync LCD1525M Macintosh cable
adapter to the computer (Figure B.1). Attach the 15-pin mini D-SUB
end of the appropriate signal cable to the MultiSync LCD1525M
Macintosh cable adapter (Figure B.1). Tighten all screws.
3. Remove connector cover and cable cover. Connect the 15-pin mini
D-SUB of the video signal cable to the appropriate connector on the
back of the monitor (Figure C.1). Place the Video Signal Cable under
Clip B.
4. Connect the audio cable to "AUDIO INPUT" on the back of the
monitor and the other end to the "Audio out" terminal of the computer.
Place the Audio cable under Clip C (Figure D.1). Replace connector
cover and cable cover.
5. Headphones may be connected to the "Headphones" output on the
front of the monitor's bezel marked " " (Figure E.1). While the
headphones are connected, the sound from the speakers will be
disabled. Headphones can be purchased from your local electronics
store.
6. Using the USB cable, connect the B type connector to the USB
upstream port on the back of the monitor and A type connector to the
downstream part on the computer (Figure F.1). If you are using the
cord from the USB device, use one of the downstream port on the
side of the monitor (Figure G.1).
NOTE: Incorrect cable connections may result in irregular
operation,damage display quality/components of
LCD module and/or shorten the module's life.
7. Connect one end of the power cord to the MultiSync LCD Series
monitor and the other end to the power outlet (Figure H.1). The
power supply cord you use must have been approved by and comply
with the safety standards of your country. (Type H05VV-F should be
used except in UK)
