4 | Assembly / Mounting
Check the LED light before installation to ensure it is complete and shows no signs of damage. Do not use the light or
accessories if they are damaged, as there is a risk of injury.
The LED light comes fully assembled. On the backside of the light is a T-slot for a mounting via T-nuts 8. As option there
are this mounting accessories:
Mounting kit, flat, with ESD insulation (Electro Static Discharge), pair
Mounting kit, one pair of T-Slot Nuts with cheese-head screws
Parts for mounting
1 Mounting bracket, flat, insulated
2 Insulating bush M6
3 Cheese head screw M6x16
4 Washer DIN 9021 A2 6.4mm
5 Hammer nut N8 M6
12 | BA SYSTEMLED SurfaceOne . BA 11/2025
When mounting the light, make sure that the luminaire is fastened securely and stably. If
the light falls down, its weight poses a risk of injury!
Installation near heat sources such as heating vents, air-conditioning units, radiant lamps,
or machines is not recommended, as these may affect the operation of the PIR sensor.
Quantity
2
2
2
2
2
Mounting kit, optional: 240400-05
Product no.
240400-05
240400-07
