15. EC Declaration of Conformity
We, ikra GmbH, Schlesier Straße 36, D-64839 Mün-
ster/Altheim, declare under our sole responsibility that
the product Electric Silent Shredder EGN 2500, to
which this declaration relates correspond to the rel-
evant basic safety and health requirements of Directives
2006/42/EC (Machinery Directive), 2004/108/EC (EMV-
Guideline), 2011/65/EU (RoHS-Guideline) and 2000/14/
EC (noise directive) incl. modifications. For the relevant
implementation of the safety and health requirements
mentioned in the Directives, the following standards and/
or technical specification(s) have been respected:
EN 60335-1:2012; EN 13683/A1:2009+A2:2011;
EN 62233:2008;
EN 55014-1/A1:2009/A2:2011; EN 55014-2/A2:2008;
EN 50581:2012
EN 61000-3-2:2006/A2:2009; EN 61000-3-11:2000
measured acoustic capacity level
guaranteed acoustic capacity level
Conformity assessment method to annexe V / Directive
2000/14/EC
The year of manufacture is printed on the nameplate and can be ad-
ditionally retrieved via the consecutive serial number.
Münster, 22.08.2014
Gerhard Knorr, Technical Management Ikra GmbH
Maintenance of technical documentation:
Gerhard Knorr, Kärcherstraße 57, DE-64839 Münster
16. Troubleshooting
PROBLEM
Motor does not run
The material is not being pulled in
GB | Operating Instructions
108 dB (A)
111 dB (A)
CAUSE
Safety lock
Power outage
The material is clogging up in the
feeding funnel.
The shredding material is too soft.
The blade is blocked.
GB-9
SOLUTION
Tighten the hand screws well.
Check the power supply cable, the
plug and the fuse.
Shut down the shredder. Pull the
material out of the feeding funnel.
Restart the shredder and insert the
thick branches in such a way that
the blade does immediately catch
in the previous cut.
Put some wood in or shred dried
branches.
Unscrew the hand screw. Open the
shredder and remove the material
causing the clog.
