Frequency Response Stereo Line Input:
Amplification Range Stereo Line Input:
Channel Crosstalk:
THD Stereo Line Input:
Impedance Stereo Line Input:
S/N Ratio Stereo Line Input:
Stereo Channel Equalizer Treble:
Stereo Channel Equalizer Bass:
Control Elements Channels 3/4 + 5/6
Main Section:
AUX/Effect Send Channels:
AUX/Effect Send Connections:
Stereo AUX Return Channels:
Stereo AUX Return Connections:
Stereo 2 TK Output Channel:
Stereo 2 TK Output Channel Connections:
Stereo 2 TK Input Channel:
Stereo 2 TK Input Channel Connections:
Unbalanced Stereo Main Outputs:
Unbalanced Stereo Main Output Connections:
Impedance Unbalanced Stereo Main Outputs:
Max. Level Unbalanced Stereo Main Outputs:
Stereo Control Room Outputs:
Stereo Control Room Output Connections:
Headphone Output:
Headphone Output Connections:
Minimum Headphone Impedance:
Digital Effects Processor:
No. of Presets:
Foot Switch Connection DFX Mute:
Control Elements Main Section:
Specifications:
Display Elements:
Power Supply:
Temperature Range For Operation:
Humidity Range For Operation:
Width:
Height:
Depth:
Weight:
Other Features:
26
10 - 45,000 Hz
50 dB
62 dB
0.0045%
3.7 kOhm
116 dB
+/-15 dB @ 12 kHz
+/-15 dB @ 80 Hz
EQ Hi, EQ Low, Aux, Bal, Level
1
6.3 mm stereo jack, unbalanced
1
2 x 6.3 mm stereo jack
1 x stereo
2 x RCA (Cinch)
1 x stereo
2 x RCA (Cinch)
1
6.3 mm stereo jack, unbalanced
120 ohms
20 dBV
1
2 x 6.3 mm jack
1
6.3 mm stereo jack
30 ohms
n/a
n/a
n/a
ST Return, 2 TK In, 2 TK In To Main/To CTRL,
Phones/CTRL, Phantom Power +48V, Main
Mix, Power
Channel Peak, Power, Phantom Power, 2 x
4-segment level display
18 V AC - 1 A, External PSU (included)
0°C to +45°C
10%rel - 80%rel
209 mm
68 mm
260 mm
1.45 kg
microphone stand adapter optional (LDVIB-
ZMSADAPTOR)
10 - 45,000 Hz
50 dB
62 dB
0.0045%
3.7 kOhm
116 dB
+/-15 dB @ 12 kHz
+/-15 dB @ 80 Hz
EQ Hi, EQ Low, DFX, Bal, Level
1
6.3 mm stereo jack, unbalanced
1
2 x 6.3 mm stereo jack
1 x stereo
2 x RCA (Cinch)
1 x stereo
2 x RCA (Cinch)
1
6.3 mm stereo jack, unbalanced
120 ohms
20 dBV
1
2 x 6.3 mm jack
1
6.3 mm stereo jack
30 ohms
yes
16
6.3 mm jack (foot switch optional)
DFX Presets, DFX Mute, DFX to Main, ST Re-
turn, 2 TK In, 2 TK In To Main/To CTRL, Phones/
CTRL, Phantom Power +48V, Main Mix, Power
Channel Peak, Effects Peak, Power, Phantom
Power, 2 x 4-segment level display
18 V AC - 1 A, External PSU (included)
0°C to +45°C
10%rel - 80%rel
209 mm
68 mm
260 mm
1.45 kg
microphone stand adapter optional (LDVIB-
ZMSADAPTOR)
