CAUTIONS
I. Pleas e readthis manual c arefullybeforeusingtheunit andretainit
for future reference.
2 . Exposin g theunit to moisture cancause fire orelectric shock.
3 . Thi s unit should notbeexposed t o temperatures
or below50 C (410 F). Dusty or humid places shouldbe avoided.
4. Donot applystrong solvents s uchasbenzine, thinners, s trong house-
hoid cleanersor pesticideson the surfaceof the unit.
NAMES OF PARTS
AC Supply Lead
e Spindl Adaptor f or 45rpmRecord———
AC Supply Voltage Selector
Centre Spindle
Turntable Platter and Mat
Automatic Lead-inAdjustment Screw
Speed Selector
PREPARATION FOR USE
AC SUPPLY VOLTAGE
ASSEMBLING
over350 C (950 F)

ADJUSTMENT

Check the preset AC mains voltage
level before plugging the AC mains
supply lead of the unit into an AC
selector setting is different from the
supply voltage, the voltage selector
(located on the baseunder the turn-
table platter) must be reset as
follows.
This unit is protected from vibration
and shocks that may occur during
transportation.Prepareit for usein
the following way.
1. Remove the turntable
from the chassis.
(1) Remove the three (3) screws
and washers.
the turntable
(2) Lift
gently from the chassis. Do
not allow the turntable
to bump anything becauseit is
a precision engineered com-
ponent.
(3} Remove the three (3) spacers.
Be sure to supply AC current to power to this unit. Operation on a
5.
different voltagelevelmay seriouslydamagethis unit or cause a fire.
SHARP can not be held responsiblefor any damageincurred during
operation with unspecifiedvoltage levels.
Alwaysremovemainsplugfrom wall socket,when not in use,or
6.
before any serviceoperation.
Neverremovecoversunlessqualified to do so; this unit contains
dangerous voltages.
platter
pl atter
platter
Output Cable
Tonearm Counterbalance Weight
Tracking Force Gauge
Tonearm Lifter
Cuing/Pause Control Lever
Tonearm Rest
Tonearm
Headshell and Cartridge
Headshell Grip
Cut-out Button
Play Start Button
Size Selector
Selector adjustment:
I. Follow step I as explained
"ASSEMBLING" on this page.
2. Slide the voltage selector to the
correct position with a screw-
driver as shown in the illustration
on the left.
the MO (2)
Remove
2.
(transit screws) from the chassis.
These screws should be replaced
when the unit is transported
therefore should be kept.
Slowly rotate the centre spindle
3.
the trip plate reaches the
until
position shown in the illustration.
Then slide the trip plate
direction of the arrow and it will
turn freely when you rotate the
centre spindle.
Hold the turntable platler
4.
your fingers as indicated in lhe
figure and gently lower it over the
centre spindle.
in
screws
and
in the
with
2
