Replacing The Heat Exchanger - Fronius Agilo Serviceanleitung

Replacing the
heat exchanger
(2)
(2)
7
8
9
10
11
12
112
(1)
(1)
(3)
(3) (3)
Fit the new heat exchanger using 4 TX25 screws - 3 Nm
Fit the ventilating fan and mounting bracket using 4 TX25 screws - 3 Nm
Fit the cover plate using 4 TX25 screws - 3 Nm
Connect the Molex plug of the ventilating fan and secure the cables with cable ties
Fit the cover plate using 16 TX25 screws - 3 Nm
Close the door
Open the door
1
(1)
Remove the 16 TX25 screws and fold
2
the cover plate forwards
Disconnect the Molex plug of ventila-
3
ting fan 2 and remove the cable ties
Undo the 4 TX25 screws (1) and remo-
4
ve the cover plate
(1)
Remove the 4 TX25 screws (2) and re-
5
move ventilating fan 2 complete with
(2)
mounting bracket
(2)
Undo the 4 TX25 screws (3) and remo-
6
ve the heat exchanger
(3)
