Let's go!
01
02
03
operation (e.g. by a DHCP router), otherwise the AC•THOR or AC•THOR 9s will lose the
control signal.
Signal sources with the addition „Modbus RTU" are connected via RS485. A network
connection (LAN) is not mandatory but is additionally recommended by my-PV to use the
cloud mode.
Select language
Use the left and right arrow keys to see more options.
Select operation mode
A comprehensive description of the operating modes and
the possible settings via the display can be found in the
operating instructions mentioned at the end.
Selection control source – where does the
AC•THOR or AC•THOR 9s get the excess
information from?
Use the left and right arrow keys to see more possibilities.
Besides the my-PV Meter and open communication
protocols such as http, Modbus TCP, Adjustable Modbus
RTU and Adjustable Modbus TCP, as well as frequency
control, pre-set signal sources are available for many
compatible manufacturers.
For some signal sources communicating via the network
(LAN), the selection between „Auto" (automatic search of
the IP address of the control) or „Manual" (manual entry of
the IP address of the control) is possible. If a control type
with the addition „Manual" is selected, the next step is to
set the IP address of the signal source.
In the case of a control mode with the addition „Manual",
the IP address of the signal source must not change during
