• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (Fig. 1-22)
1. Steering
2. Drive bow
3. Engine brake lever
4. Upper push bar
5. Quick clamp lever
6. Plastic star grip nut
7. Cable clip
8. Lower push bar
9. Guide (push bar)
10. Fuel filler cap
11. Fuel tank
12. Air filter cover
12a. Air filter
13. -
14. Water connection
15. Idler
16. Spark plug connector
16a. Spark plug
17. Exhaust pipe
18. Oil dipstick
19. Side discharge flap
19a. Side discharge
20. Cutting height adjustment
21. Drive wheel
22. Discharge flap
23. Grass collection basket
24. Rope hook
25. Pull starter
26. Mulching insert
27. Blade
28. Blade screw
29. Washer
30. Engine spindle
31. Carburettor screw
32. V-belt
3 Scope of delivery (Fig. 1-2)
Item QuantityDesignation
4. 1 x Petrol lawnmower with upper push bar
5. 2 x Quick clamp lever
6. 4 x Plastic star grip nut
7. 1 x Cable clip
8. 1 x Lower push bar
9. 2 x
19a. 1 x
23. 1 x
26. 1 x
A. 2 x
B. 2 x
C. 2 x
D. 2 x
1 x
4 Proper use
The petrol lawnmower is intended for private use i.e. for
use in home and gardening environments. Private use of
the lawnmower refers an annual operating time generally
not exceeding that of 50 hours, during which time the ma-
chine is primarily used to maintain small-scale, residential
lawns and home/hobby gardens. Public facilities, sporting
halls, and agricultural/forestry applications are excluded.
The product may only be used in the intended manner.
Any use beyond this is improper. The user, not the manu-
facturer, is responsible for damages or injuries of any type
resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Due to physical danger to the user, the lawnmower must
not be used for the following work (incomplete list):
• for trimming bushes, hedges and shrubs,
• for cutting climbing plants,
• for lawn care on roof plantings and in balcony boxes,
• for chipping and shredding tree and hedge cuttings,
• for cleaning pavements (vacuuming, blowing away),
• for levelling ground elevations, such as molehills.
• for transporting cuttings, except in the grass collection
basket provided.
WARNING
For your own safety, please thoroughly read this manu-
al and the general safety instructions before turning the
product on. If you give the product to third parties, al-
ways include these usage instructions.
www.scheppach.com
Guide (push bar)
Side discharge
Grass collection basket
Mulching insert
Screw M8
Washer, small
Washer, large
Spacer
Operating manual
