Configuratio
n
Switching time
The switching time can be set individually.
◆
If the switching time is set to 0, the
◆
selected output remains activated until the
other output is selected.
If the switching time is set to a value greater
◆
than 0, the output is only activated for the
duration of the switching time.
Switching time
switched.
The configured value is multiplied by
◆
10ms.
Switching pulses from 10ms to 2,550ms are
◆
possible in steps of 10ms.
Outputs
Milliseconds
1 second corresponds to 1,000 milliseconds
◆
The default value of 40 means a
◆
switching time of 400ms, i.e. 0.4 seconds.
Example of continuous operation
Switching time is 0
◆
The output is switched by the green command
◆
on the control panel.
The output remains switched until the
◆
control panel switches to red.
Example switching pulse
Switching time is 40
◆
The output is switched by the green command
◆
on the control panel.
The output is automatically switched off
◆
after 400 milliseconds.
Careful
For continuous operation of the outputs,
◆
ensure that the maximum load of the
outputs does not exceed 500mA.
The outputs are designed for up to 2A for
◆
short periods, but this does not apply to
the
Continuous operation.
