Commissioning
Automatic learning mo dus
The decoder has an automatic learning mode
◆
for addressing.
To start the automatic learning mode, press
◆
the button.
In learning mode, the decoder waits for the
◆
next command from the central unit and
assigns the address to the output.
The received command is also executed for
◆
confirmation, i.e. the output is switched.
Assign address
If no command is received within 60 seconds
◆
or if the button is pressed again
is pressed, the learning mode is ended.
Address
An individual address can be assigned to the
◆
output. The address is free
selectable.
Example
1)
Press the button on the decoder.
2)
The decoder waits for the next command.
3)
Execute a switch command at the control center,
e.g. turnout 22 to green.
4) The decoder receives the command and
assigns address 22 to the output.
5) The decoder switches the output.
6) The decoder exits the learning mode.
9
