Electric Wiring and the Application
• Each outdoor must be earthed well.
• The appliance shall be installed in accordance with national wiring regulations.
• All wiring must be performed by an authorized electrician.
• Be sure to install an earth leakage circuit breaker in accordance with applicable legislation.Failure to do so many cause
electrical shock.
Outdoor power input
Model
AW042HUGHA
AW062HUGHA
AW082HUGHA
AW102HUGHA
AW122HVGHA
AW142HVGHA
AW162HVGHA
AW10NHUGHA
AW12NHVGHA
AW14NHVGHA
AW16NHVGHA
(1) Water 12/7°C - Outdoor 35°C
(2) Water 40/45°C - Outdoor 7°C DB/6°C WB
Communication wire to HU indoor unit
Length of Signal Line (m)
≤1000
• The shielding lay of the signal line must be grounded at two side.
COOLING(1)kW
0.73
1.12
1.50
1.96
2.35
2.83
3.23
1.96
2.35
2.83
3.23
Wiring Dimensions
2
0.75mm × 2 core shielding line
HEATING(2)/kW
0.90
1.39
1.83
2.41
2.80
3.37
3.94
2.41
2.80
3.37
3.94
32
MAX/kW
2.9
2.9
4.0
4.0
6.6
6.6
7.5
4.0
6.6
6.6
7.5
