Functions and operation of the wall controller
OFF position- Position 1-
Fan off High fan speed
Setting fan direction for summer and winter
Your ceiling fan can operate in either summer or winter mode.
Summer mode - The reverse switch should be in the SUMMER position to make the fan rotate in a clockwise direction. The
airflow will be directed downwards, for cooling in summer.
Winter mode - The reverse switch should be in the WINTER position to make the fan rotate in a counter clockwise direction.
The airflow will be directed upwards assisting in the circulation of warm air, for energy conservation in winter.
Reverse
Winter
switch
Fan Installation Instructions | Version 1.25
12 SWING Boulder
Position 2-
Medium fan speed
Summer
Position 3- Toggle switch –
Low fan speed
Fan speed rotary switch
Light toggle switch
Summer
Downwards airflow
Clockwise rotation Counter clockwise rotation
Light On/Off
Winter
Upwards airflow
