Swing BOULDER Montageanleitung Seite 11

8. Fitting the blades
- Loosen the screws from the light base and remove the light base from the fan motor (Figure 1).
- Remove the 3 blade screws from the fan motor (Figure 2).
- Insert the blade through the slots on the side of the fan motor.
- Insert the 3 screws through the blade and secure them to the motor. (Figure 3).
- Repeat this securing process for all other blades.
-Put the light base back in place and tighten the screws on the light base. (Figure 4).
1 2
3 4
9. Installing the light fitting
- Insert and rotate the light fitting counterclockwise to lock in place.
11
