2 Operation
2.2.1 Controls and Indicators
The design of DEEP OSCILLATION
Due to its small size, the device is easily transportable. It has been designed for use outside of therapy
rooms, and it runs by a rechargeable battery.
All controls and indicators are integrated into the casing, thus allowing for easy cleaning of the device's
surface. The device's microprocessor monitors the safety-related components, prevents from erroneous
operation and checks all functions of the device after switching it on.
The following section introduces the individual indicators and controls of DEEP OSCILLATION
Home. The numbers in angle brackets refer to the
2.2.1.1 Display <1>
Symbols in the Display
Button Back
Charging Status
Indications
Individual Programs (cannot be selected in this version of the product)
Settings Menu (refer to
®
DEEP OSCILLATION Personal Home
®
Personal Home allows for easy operation, despite a variety of functions.
Device Overview
In the Display <1> the available options or therapy
parameters are shown, depending on the context.
The battery symbol on the upper right corner shows
the current charging condition of the batteries (also
refer to
A parameter can be selected by using the Data Se-
lector <2>.
Settings on page 20)
PHYSIOMED ELEKTROMEDIZIN AG
on page 8.
Charging the Device on page 13).
®
