DESIGN AND APPLICATION
The angle grinder is a hand-held power tool with the II class isolation. The power tool is driven with a single-
phase, commutator motor, whose rotational speed is reduced by means of an intersecting axis gear. The
power tool can used both for grinding and cutting. This type of power tools is widely used for removal of
burrs from metal surfaces, weld surface processing, cutting light-wall tubes and other small metal objects
etc. They are used in engineering industry, automotive and chemical industry. With the use of proper tools,
the angle grinder can be used not only for cutting or grinding, but also for rust and paint coats removal.
The areas of its application include repair and construction works, not only related to metals. The angle
grinder can also be used for cutting and grinding of construction materials, such as brick, paving stones,
ceramic tiles, etc.
The power tool is designed for dry operation only and it must not be used for polishing. The power
tool should be used according to its purpose.
Use inconsistent with its purpose
• Do not work materials that contain asbestos. Asbestos is carcinogenic.
• Do not work materials, whose dust is inflammable or explosive. During operation, the power tool
produces sparks, which may ignite emitted vapours.
• Do not use cut-off wheels for grinding. The cut-off wheels are used to cut with its face, while grinding with
lateral surface of such a cut-off wheel threatens with its damages and puts the operate in danger of injuries.
DESCRIPTION OF GRAPHIC PAGES
The below list refers to device components shown in the graphic pages of this instruction manual.
1. Spindle lock button
2. Switch
3. Additional handle
4. Grinding wheel cover
5. External flange
6. Internal flange
10. Lever (grinding disc guard)
* There can be differences between the drawing and actual product.
DESCRIPTION OF USED GRAPHIC SIGNS
NOTE
WARNING
FITTING/SETTING
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Grinding wheel guard
2. Socket spanner
3. Additional handle
ATTACHING THE ADDITIONAL HANDLE
The additional handle (3) is installed in one of the holes in the grinder head. It is recommended to use the
grinder with the additional handle. When holding the grinder with both hands (also using the additional
handle), there is less risk of touching the grinder wheel or brush with your hand, as well as of injuries during
recoil.
- 1 pce
- 1 pce
- 1 pce
PREPARATION FOR WORK
19
