ENGLISH
4. Installation

4.1. Preliminary checks

To ensure safety and an efficiently operating automated system,
make sure the following conditions are observed:
• The enclosures of the control boards (see relevant instructions)
should be installed at a distance from the operators not requi
ring the motor cable to be extended.
• The structure of the gate must be suitable for being automated.
In particular, check that the structure is sufficiently strong and
rigid, and that its dimensions and weight conform to those
indicated in the technical specifications.
• Make sure that the leaves move uniformly and correctly, without
any irregular friction during their entire travel.
• Make sure that the hinges are in good condition.
• Check if the mechanical stops of the limit-switches are fitted.
• Remove any locks and lock bolts.
We advise you to have any metalwork carried out before the
automated system is installed.
Z = see Fig. 3
Tab. 2 - Installation dimensions
88 ÷ 91
30 ÷ 39
40 ÷ 49
50 ÷ 59
60 ÷ 69
70 ÷ 79
80 ÷ 89
90 ÷ 99
100 ÷ 109
110 ÷ 119
120 ÷ 129
130 ÷ 140
The intersection of dimensions D and B (see Fig. 4) in the table determines which fixing hole on the bracket should be used.
Note: Intersections without figures cannot be used.
Example:
• For a D dimension of 45 mm and a B dimension of 100 mm, use the 4th hole (100° opening).
• For a D dimension of 45 mm and a B dimension of 105 mm, use the 4th hole (90° opening).
92 ÷ 97
98 ÷ 102
100°
90°
100°
90°
100°
90°
100°
90°

4.2. Installation dimensions

There are 4 possible installation dimensions Z as shown in Fig. 3.
1
hole
st
2
hole
nd
3
hole
rd
4
hole
th
• Dimensions in mm
Do not , on any account, cut the rear bracket to obtain dimension
A (Fig. 4).
Establish the installation position of the operator by referring to Fig.
4 and Table 2.
B
103 ÷ 107
100°
90°
100°
90°
100°
90°
100°
90°
6
520
• Dimensions in mm
108 ÷ 113
114 ÷ 119
90°
90°
90°
100°
90°
• Dimensions in mm
Fig.3
Fig.4
120 ÷ 126
90°
