underside of the multifunction machine fig. C2. Then install the adapter
fig. A7 for connection to a hoover.
Installation of accessories
Accessories should be selected according to the work to be carried out.
The accessory can be changed without tools, and the magnet in the
toolholder makes it very easy to fit. The accessories are mounted in the
toolholder, fig. A1. The installation sequence of the individual components
is shown in fig. C. On the head there are tabs fig. C2 and on the
accessories there are positioning holes fig. C6. The holes with the tabs
must be aligned to avoid movement of the working tool during operation.
The first step in installing the accessory is to unlock the handle by lifting
the locking mechanism fig. A4. The next step is to position the working
tool so that the holes in the tool fig. C6 are aligned with the tabs in the
handle fig. C2. The tool lock is then carefully lowered. When the locking
device is in position fig. C3 lower the finger protection fig. C5b into the
recesses fig. C5b, holding it down lower the locking device to the end. The
lock has to be in the position shown in fig. C4. Once you are sure that the
accessory is correctly installed you can start working.
Installation of an auxiliary handle
The multifunction machine can be used with one hand, but it is possible to
work with two hands by installing an additional handle Fig. A 10. The
additional handle provides greater comfort and certainty when holding the
machine when there is good access to the work area. The handle can be
removed when working in hard-to-reach areas. The handle can be
installed on the right or left side of the unit in the threaded holes fig. A 10
by tightening firmly
Working with the device
Choosing the right tool is a very important part of the job, the correct choice
will make the work easier and faster. The choice of tool will depend on the
nature of the work to be done: sanding, scraping, cutting, and the material
to be worked in: wood, metal, plastic. The machine is equipped with a
speed regulator, fig. A9; higher speeds translate into higher oscillation and
more intensive work. Apply the machine to the material to be worked on
once it has reached the desired speed
MAINTENANCE AND STORAGE
ATTENTION! Unplug the power cord from the mains socket before
carrying out any installation, adjustment, repair or operation.
• Keep the unit clean at all times.
• Do not use water or other liquids for cleaning
• Clean the power tool with a brush or a dry piece of cloth.
• Clean the working tools with a wire brush.
• Clean the ventilation slots regularly to prevent the engine from
overheating.
• If excessive sparking occurs on the commutator, have the condition
of the motor's carbon brushes checked by a qualified person.
• Always store the device in a dry and shaded place, out of the reach
of children.
KIT CONTENTS:
• Multifunctional device
• Dust extraction
• Additional handle
• Sanding pad with Velcro
• Scraping accessories
• papers
• Transport case
RATING DATA
Multifunction machine 59G025
Parameter
Supply voltage
Rated power
Number of oscillations
Length of supply cable
Degree of protection
Protection class
Mass
Year of production
59G025 indicates both the type and the machine designation
NOISE AND VIBRATION DATA
Sound pressure level
Sanding mode
Sawing mode
Scraping mode
1 pc.
1 pc.
1 pc.
1 pc.
5 pcs.
5 pcs.
1 pc.
Value
230V 50Hz
500 W
-1
8000-16000 min
3 m
IPX0
II
1.5 kg
2025
Lp
=102 dB(A) K=3
A
dB(A)
Sound power level
Sanding mode
Sawing mode
Scraping mode
Vibration acceleration values
Sanding mode
Sawing mode
Scraping mode
Information on noise and vibration
The noise emission level of the equipment is described by: the emitted
sound pressure level Lp
denotes measurement uncertainty). The vibration emitted by the
equipment is described by the vibration acceleration value a
is the measurement uncertainty).
The sound pressure level Lp
vibration acceleration value a
measured in accordance with EN 62841-1:2015. The vibration level a
given can be used to compare equipment and to make a preliminary
assessment of vibration exposure.
The vibration level quoted is only representative of the basic use of the
unit. If the unit is used for other applications or with other work tools,
the vibration level may change. A higher vibration level will be
influenced by insufficient or too infrequent maintenance of the unit. The
reasons given above may result in increased vibration exposure during
the entire working period.
In order to accurately estimate vibration exposure, it is necessary to
take into account periods when the unit is switched off or when it is
switched on but not used for work. Once all factors have been
accurately estimated, the total vibration exposure may turn out to be
much lower.
In order to protect the user from the effects of vibration, additional safety
measures should be implemented, such as cyclical maintenance of the
machine and working tools, securing an adequate hand temperature
and proper work organisation.
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with
household waste, but should be taken to appropriate facilities for
disposal. Contact your product dealer or local authority for information
on disposal. Waste electrical and electronic equipment contains
substances that are not environmentally friendly. Unrecycled
equipment poses a potential risk to the environment and human
health.
"GTX Poland Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "GTX Poland ") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including among
others. All copyrights to the contents of this Manual (hereinafter referred to as "Manual"),
including but not limited to its text, photographs, diagrams, drawings, as well as its
composition, belong exclusively to GTX Poland and are subject to legal protection
pursuant to the Act of February 4, 1994 on Copyright and Related Rights (i.e. Journal of
Laws 2006 No. 90 Item 631 as amended). Copying, processing, publishing, modifying for
commercial purposes the entire Manual as well as its individual elements without the
written consent of GTX Poland is strictly prohibited and may result in civil and criminal
liability.
EC Declaration of Conformity
Manufacturer: GTX Poland Sp. z o.o. Sp.k,
2/4 Pograniczna Street 02-285 Warsaw
Product: Multifunctional device
Model: 59G025
Trade name: GRAPHITE
Serial number: 00001 ÷ 99999
The product described above complies with the following
documents:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And meets the requirements of the standards:
EN 62841-1: 2015 + A11: 2022 EN 62841-2-4: 2014
EN IEC 55014-1:2021 EN IEC 55014-2:2021 EN IEC 61000-3-
2:2019+A1:2021 EN 61000-3-3:2013+A1:2019+A2:2021
EN IEC 63000:2018
This declaration relates only to the machinery as placed on the market and
does not include components
7
Lp
=107 dB(A) K=3
A
dB(A)
Lp
=104 dB(A) K=3
A
dB(A)
Lw
=113 dB(A) K=3
A
dB(A)
Lw
=118 dB(A) K=3
A
dB(A)
Lw
=115 dB(A) K=3
A
dB(A)
2
a
)<2.5 m/s
(h
2
a
=5.9 m/s
h
2
a
=5.5 m/s
h
and the sound power level Lw
A
, the sound power level Lw
A
given in these instructions have been
h
2
K=1.5 m/s
2
K=1.5 m/s
2
K=1.5 m/s
(where K
A
(where K
h
and the
A
h
