SOLARWATT Battery vision Bedienungsanleitung Seite 11

INVERTER ASSEMBLY AND WIRING
detail 1
Inverter interfaces
BMS Battery
Connect Battery (6, 4)
Subject to change | Solarwatt GmbH
detail 2
25 24
PIN meter 24
PIN RJ45 plug for the inverter 2
Connect meter
1 2
25
1
11
