Preconditions:
a
The product is disconnected from the power supply and hose.
1. Remove 8x base plate screws.
2. Separate the base from the motor unit.
3. Remove 3x cover plate screws.
4. Separate the cover from the motor unit.
5. Clear any obstructions (e.g., use a low power fresh water hose).
6. Replace all parts and screws when cleaning is complete.
14 Cleaning and repairs
14.1 Cleaning
Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They damage the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the product from the power supply.
2. Clean the product with a fibre-free cloth.
3. If needed, rinse the product using fresh water from a low powered hose.
4. Remove any trapped debris. See section:
14.2 Repairs
Never open the motor housing. Any repair work must be carried out by a qualified
professional.
15 Troubleshooting
Problem
Possible cause
The pump fails to
The power supply is cut off.
start.
Fails to start in auto mode.
The induction pins are dirty.
Over heat protection has triggered. Clear any blockages. See sec-
Dirt / debris is preventing suction.
The pump fails to
The non-return valve is not in-
stop in auto mode.
stalled correctly or damaged.
The induction pins are dirty.
Damp leaves are covering the in-
duction pins.
Debris is blocking the non-return
valve.
The pump is in manual mode.
Low pumping effi-
The water inlet is blocked.
ciency or failure.
The air exhaust is blocked.
The outlet hose is blocked.
The hose outlet is too high above
the pump.
The non-return valve is not in-
stalled correctly or damaged.
16 Technical data
16.1 General
Operating voltage ........................... 230 V/AC, 50 Hz
Rated power ................................... 400 W
Protection class .............................. I
Ingress protection........................... IPX8
Overheat protection........................ yes (135 °C)
Dry run protection........................... yes (auto mode)
Auto mode ...................................... Water level:
Manual mode.................................. Auto shut off disabled
Power cable.................................... H05RN-F 3G 0.75 mm²
9
Clearing blockages
[} 8].
Solutions
Check the power supply.
Check if the water level is
lower than 26 mm. 26 mm is
the height at which the pump
automatically switches off.
Clean the induction pins.
tion:
Clearing blockages
Inspect the non-return valve.
Clean the induction pins.
Remove any debris from the
induction pins.
Inspect and clear the non-re-
turn valve.
Switch to auto mode.
Clear any blockages. See sec-
tion:
Clearing blockages
Check if there are any kinks in
the hose.
Make sure the hose does not
lift more than 7m above the
pump.
Inspect the non-return valve.
Pump ON: >26 mm
Pump OFF: <26 mm
min. water level 13 mm
Power cable length......................... 10 m
Grain size ....................................... max. 5 mm
Flow rate......................................... max. 7000 l/h
Discharge head .............................. max. 10 m
Suction height................................. max. 7 m
Immersion depth............................. max. 7 m
Water temperature.......................... max. +35 °C
Pumped fluid................................... Clear, fresh, non-potable water
Outlet: hose connection.................. 25.4 mm (1") or 31.75 mm (1 1/4")
Operating / storage conditions........ 0 to +35 °C
Dimensions (W x H x D) ................. 320 x 170 x 223 mm
Weight ............................................ 4.18 kg
16.2 Performance chart
[} 8].
[} 8].
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication reflects the technical status at the time of printing.
Copyright by Conrad Electronic SE.
*2997639_V2_0425_dh_mh_en 9007200373879691-2 I2/O2 en
