4.3 Replacing the Caterpillar Tread
1. Remove the side cover plate from the
device: Lay the device on its side,
remove the 4 clips on the side cover
plate with the flathead screwdriver,
and pull out the side cover plate
upwards.
3. Remove the rear wheel and caterpillar tread of the device by gently pulling on each
piece.
4. Align the gears of the
replacement caterpillar tread with
the gears on both wheels.
Reinstall the rear wheel and the
caterpillar tread, ensuring they are
secured along the tread sleeves.
2. Remove the screws and the guide
sleeve from the rear wheel.
