3. Safety Distances
The indicated safety distances apply to fl ammable
materials or materials with fl ammable parts with a
thermal resistance of R ≤ 6 m²K/W.
For particularly temperature-sensitive materials like
glass, larger distances may be necessary.
Within a radius of 110 cm in front, 80 cm on the right
and 20 cm on the left side of the stove, fl ammable,
combustible, or heat-sensitive materials (e.g. furni-
ture, wood or plastic panelling, curtains, etc.) are
not allowed to be located in the heat radiating area
of the fi re box window (fi g. 1).
Outside the radiation area of the fi re box window, a
safety distance of 5 cm sideways and 7 cm behind
the stove is to comply to fl ammable materials (fi g.
1). Above the stove, the safety distance of 65 cm to
fl ammable materials has to be complied with (fi g. 2).
No fl ammable or temperature-sensitive materials
may be present around the fl ue pipe connection
(Connection opening in the wall or ceiling). Note the
respective national regulations.
WARNING!
Flammable fl ooring materials (e.g., wood,
laminate, carpeting,) must be protected
with a fl oorplate made of non-combustible
material (e.g., tiles, safety glass, slate, or
sheet steel).
The size of the fl oorplate must be larg-
er than the base of the stove by at least
50 cm in front and at least 30 cm at the
sides of the stove (fi g. 3).
80*
20
110
80*
5*
110
fi g. 1
* For highly-insulated components with a thermal
insulation resistance of R ≤ 6 m²K/W, the existing
gaps should be extended to 5 cm.
fi g. 2
50
11
30
50
fi g. 3 fi g. 3
Dimensions in cm
en
fl oor-
plate
