STEP1:
Install the wheels
Prepare the following items.
D
-split pin*2
K
-support pole*2
Firstly, align the holes of the P-powder shuffle and Q-main framework.Paying
attention to the orientation of the P-powder baffle as shown in the figure.Then
thread the N-wheel axle through the P-powder baffle, Q-main framework, and
O-mixer in sequence.
INSTALLATION
G H
-short spring*4
N O
-wheel axle*2
I
-M12x12
-gasket*8
head nut*4
P
-mixer*1 -powder baffle*1
4
round
J-wheel*4
Q
-main
framework*1
