VEVOR R802 Bedienungsanleitung

210x145mm 120g铜版纸
封底
E-mail: CustomerService@vevor.com
No Description Qty. No Description
1 Gun Body 1 25 Switch pole
2 Needle Seal 1 Air cap
26
3 Ring Locking 1 27 Nozzle
4 Spring Direction 1 28 Nozzle sealing washer
5 Screw Needle 29 Shunt RingFilter
1
6 Needle Spring 1 30 Fluid Inlet sealing washer
7 Joint 1 31 Filter
8 Fluid Adj. Knob 32 Cup
1
9 Phillips Screw 1 33
Trigger Washer
10 Pattern Adj. Knob 1 34 Retainer Washer
11 Pattern Adj. Washer 1 35 Trigger
12 Pattern Adj. Bolt 1 36 Curved Washer
13 37
Pattern Adj. Seat 1 Trigger Pusher
14 O-ring 11*1Pattern 1 38 Trigger Pin
15 Block 39 Cup Lid
1
16 40
Pressure Adj. Knob 1 /
17 1
Pressure Adj. Seal Ring 41 /
18 Regulator 1 42 /
19 Self Tapping Screw 1 43
/
20 1 44
Switch spring Bull Hex wrench
21 45
Switch end cap 1 Bovine Hex wrench
22 46
Position screw 1 Brush
23 47
Air inlet plug 1 Hex Wrench
24 48
Switch seat 1 Hook
Manufacturer: Zhejiang Rongpeng Air Tools Co.,Ltd.
Address: Shuiquetou Village,Pengjie Town,Luqiao District,Taizhou City,Zhejiang Province,China,318057
Made in China
09
Solution
Symptom Problems
1. Add material into container.
1. Sticking air valve stem.
2. Hold more upright.
Air leaking from air 2. Contaminate on air valve or seat.
3. Tighten.
cap without pulling 3. Worn or damaged air valve or seat.
4. Adjust or replace.
trigger. 4. Broken air valve spring.
5. Lubricate and or tighten.
5. Bent valve stem.
6. Clear vent hole.
1. Tighten, but do not restrict
Fluid leaking from 1. Packing nut loose. needle.
packing nut. 2. Packing worn or dry. 2. Replace or lubricate.
(non-silicone oil)
1. Too high atomization pressure 1. Reduce pressure.
2. Too far from work surface 2. Adjust to proper distance.
Excessive overspray.
3. Improper stroking. 3. Move at moderate pace,
(arcing, gun motion too fast) parallel to surface.
1. Check air lines.
1. No pressure at gun.
2. Open fluid control.
Will not spray. 2. Fluid control not open enough.
Thin fluid or change to
3. Fluid too heavy.
pressure feed system.
07
封面
AIR POWERED HVLP SPRAY GUN
User Manual
DESCRIPTION
Qty.
1
1
1
1
Low volume low pressure technology applies paint with less force, meaning less "bounce" of the
surface into the air, Stainless steel needle and nozzle to accommodate a variety of coatings, Just the
1
paint gun for covering small areas and touch-up work. New ergonomic designed handled for
comfortable grip.
1
1
TECHNICAL DATA
1
1
Type of Feed Gravity
1
Air inlet 1/4"
1
Standard Dia of Nozzle 1.3mm、1.7mm
1
Recommended air pressure 2.0-3.5bar (28.8 – 51psi)
1
1
Max. pressure of air 6.8 bar (100psi)
1
Paint Capacity
1000cc
1
Avg. Air Consumption 84.1 – 109l/min (3.5-3.9cfm)
1
Patten width
180-260mm (7.0"-10.2")
1
1
Weight
0.956kgs (2.1 lbs)
1
1
1
IMPORTANT SAFETY INSTRUCTIONS
1
1. Toxic vapors produced by spraying certain materials can create intoxication and serious damage to
1
health. Always wear safety glasses, gloves and respirator to prevent the toxic vapor hazard, solvent
and pointing paint coming into contact your eyes or skin. (see fig 1)
fig 1
02
INSTRUCTIONS FOR OPERATION
Preparation
1. After unpacking the product, inspect carefully for any damage that may have occurred during
transit. Make sure to tighten fittings, bolts, etc., before putting unit into service.
2. Thoroughly mix and thin paint in accordance with the paint manufacturer's instructions.
Most materials will spray readily if thinned properly.
3. Strain material through filter, cheese cloth or a paint strainer.
4. Fill the canister about ¾ full and start the air compressor.
WARNING！
DO NOT EXCEED Spray Gun or any other parts in the compressor system MAXIMUM PRESSURE.
5. After connect the gun to air supply, please make sure that the fluid cap, container and air hose have
been connected tightly with spray gun.
6. Set up a piece of cardboard or other scrap material to use as a target and adjust for best spray
pattern.
WARNING！
Never aim or spray at yourself or anybody else which would cause serious injury.
7. Test the consistency of the material by making a few strokes on a cardboard target. If material still
appears too thick, add a small amount of thinner. THIN WITH CARE! Do not exceed paint
manufacturer's thinning recommendations.
Adjustment
The desired pattern, volume of fluid output and fine atomization can easily be obtained by
regulating the Pattern Adjusting Knob, Fluid Adjusting Knob and Air Adjusting Knob.
PATTERN ADJUSTMENT: Turning Pattern Adjusting Knob to the right until tight will make spray
pattern round, or turning left make spray pattern ellipse.
Material (PAINT) ADJUSTMENT: Turn the Paint Adjusting Knob clockwise will decrease the volume of
fluid output and counter-clockwise will increase fluid output.
AIR Inlet ADJUSTMENT: Turning the Air Adjusting valve clockwise will decrease the air volume.
And counter-clockwise will increase the air volume.
04
AIR POWERED
HVLP SPRAY GUN
User Manual
Model Number: R802
This is the original instruction, please read all manual instructions carefully before operating.
VEVOR reserves clear interpretation of our user manual. The appearance of the product shall
be subject to the product you received. Please forgive us that we won't inform you again if
there is any technology or software updates on our product.
01
2. Never use oxygen, combustible or any other bottle gas as a power source or would cause
explosion and serious personal injury. (see fig 2)
Carbpn Dioxide
Hydrpgem
Notrpgem
Oxygen
fig 2
3. Fluid and solvent can be highly flammable or combustible. Use in well-ventilated spray booth and
avoid any ignition sources, such as smoking, open flames and decrial hazard. (see fig 3)
fig 3
4. Disconnect tool from air supply hose before doing tool maintenance and during non-operation,
for emerge stop and prevention of unintended operation, a ball valve near the gun to air supply
is recommend.
5. Use clean, dry and regulate compressed air rated at 2.0~3.5bar, never exceed maximum permissive
operating pressure. (see fig 4)
fig 4
6. Never use homogenate hydrocarbon solvent, which can chemically react with aluminum and zinc
parts and chemically compatible with aluminum and zinc pats.
7. Never point gun at you and others at any time.
8. Before operating the tool, make sure all the screws & caps are securely tightened in case of leaking.
9. Before painting, make inspection for free movement of trigger and nozzle to insure tool can operate
well.
10. Never modify this tool for any applications. Only use parts, nozzles and accessories recommended
and accessories recommended by manufactures.
11. Notes to the effect that the equipment should be only be used in a well ventilated area.
03
Operation
1. Begin spraying. Always keep the gun at right angles to the work .
2. Keep the nozzle about 6 to 12 inches from the work surface. Grip the gun keeping perpendicular
with spraying area then move it parallel for several times. Stopping gun movement in mid-stroke
will cause a build up of paint and result in runs. Do not fan the gun from side to side while painting.
This will cause a build-up of paint in the center of the stroke and an insufficient coating at each end.
3. Trigger the gun properly. Start the gun moving at the beginning of the stroke BEFORE SQUEEZING
THE TRIGGER and release the trigger BEFORE STOPPING GUN MOVEMENT at the end of the stroke.
This procedure will blend each stroke with the next without showing overlap or unevenness .
4. The amount of paint being applied can be varied by the speed of the stroke, distance from the
surface and adjustment of the fluid control knob.
5. Overlap strokes just enough to obtain an even coat.
NOTE：
Two thin coats of paint will yield better results and have less chance of runs than one heavy layer.
6. Use a piece of cardboard as a shield to catch overspray at the edges of the work to protect other
surfaces.
MAINTENANCE
Incomplete cleaning could cause function failures and a degradation of the fan form.
1. Remove any remaining paint by pouring it into another container.
2. Disassemble the spray gun making sure to remove the needle before disassembling the nozzle to
avoid damage to the housing of the nozzle closure.
3. Clean all the paint passages and the nozzle. Clean the other components using a brush soaked in
solvent.
4. Reassemble the spray gun and spray a small quantity of solvent to eliminate all the residues in
the paint passages.
05
PARTS LIST
08
WARNING！
Never use metal or other objects that could damage the holes in the nozzle and cap.
Never immerse the spray gun completely in solvent. Never use components or parts that are not
manufacturer originals.
Storing
1. When not using spray gun, turn the fluid adjustment knob counter-clockwise to open which will
reduce spring tension on needle fluid tip.
2. Spray gun MUST BE well cleaned and lightly lubricated.
Trouble shooting
Solution
Symptom Problems
1. Material level tool low. 1. Add material into container.
2. Container tipped too far. 2. Hold more upright.
3. Loose fluid inlet connection. 3. Tighten.
4. Loose or damaged fluid tip/seat. 4. Adjust or replace.
5. Dry or loose fluid needle packing nut. 5. Lubricate and or tighten.
Fluttering or spitting.
6. Air vent clogged 6. Clear vent hole.
1. Tighten or replace Fluid
nozzle.
1. Worn or loose Fluid nozzle.
2. Remove obstructions from
2. Material build up on Air cap.
hoes, but don't use metal
Pattern is arc.
objects to clean it.
1. Material build up on Air cap. 1. Clean or replace Air cap.
Pattern is not
2. Fluid nozzle dirty or worn. 2. Clean or replace Fluid nozzle.
Evenly spread.
1. Material too thin or not enough. 1. Regulate material viscosity.
2. Atomization air pressure too high. 2. Reduce air pressure.
The center of Pattern
too narrow.
1. Regulate material viscosity.
1. Material too thick.
Pattern width of 2. Increase air pressure.
2. Atomization air pressure too low.
fan-sharp is not
enough.
