Operating mode
In the task selection interface, long press the center key to enter the parameter
modifcation mode, the modifable parameters will flash; Short/long press the
left/right key to modify the parameter value, short press the center key to switch
to the next parameter for modifcation; Long press the center key to save and exit
parameter modifcation mode; In the task selection interface short press the center
key to start the current task, long press the left/right key to return to the main page;
During the charging task, the charging current can be adjusted by long pressing the
center key, and short pressing the center key ends the current task.
①: Charging Sign; ②: Battery Type; ③: Number of Cells;
④: Charging Current; ⑤: Battery Charged Capacity; ⑥: Task progress bar;
⑦: Current Battery Voltage; ⑧: Input Voltage Sign;⑨: Wireless Connection Sign;
⑩: Temperature in Celcius and Fahrenheit;
Note: ① Standby mode:
When powered by PD protocol and start charging:
upon the completion of the task;
⑧ When powered by DC power supply:
The following two numbers are the input voltage and input power;
If the PD protocol is used, the amount of power supplied can be displayed.
⑩Celsius and Fahrenheit.
: Input Current;
; When powered by DC power supply and start charging:
; When powered by TYPE-C power supply:
; The status indicator will turn green
;
