ISDT 608PD Bedienungsanleitung Seite 15

ing,
in
arging
alue
he
e
um
pported
ithium
ging time
e charging
ete the
will appear
report an
nnection of
y voltage.
②: Ausgewählte Aufgabe; ③: Akkutyp; ④: Anzahl der Zellen;
⑤: Zielspannung (volle Ladespannung);
⑥: Ladestrom; ⑦: Anzeige der linken Taste; ⑧: Anzeige der Menütaste;
⑨: Anzeige der rechten Taste
Preset Battery Type of Charger and Task Parameters
Rated voltage
Full charge voltage
Balance charge
Unbalanced charge
Supported cell count
Max. charging current
Operating the Charger
Connect the 608PD to the power supply, connect the battery, short/long
press the center button to enter the charging parameter selection interface:
①:Preset task sequence number (Up to fve preset charging parameters);
②:Selected Task; ③:Battery Type; ④: Number of Cells;
⑤:Target Voltage (Full Charge Voltage);
⑥:Charging Current; ⑦:Left Button Indication; ⑧: Menu Key Indication;
⑨:Right Button Indication
