Product Specifcations
Max input current: DC 10A, USB-C 5A
Input voltage: DC 5-30V,USB-C 5-28V
Output voltage: DC 3.0~30V
Balance current: 0.8A/Cell Max
Working temperature: 0~40℃
Storage temperature:-20~60℃
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Supported battery types and cell: LiFe, LiPo,
How to Confrm Charging Current
Make sure to know the maximum charging current of the battery before charging,
never use excessive current to charge to damage your battery, which will result in
over heat even explosion during the charging process.The charging and discharging
capacity of battery is usually marked with C value. Multiplying the charging C value
and battery capacity equals to the maximum charging current supported by the
battery. For example, for a 1000 mAh battery with a charging capacity of 5C, the
maximum charging current would be 1000*5=5000mA; therefore, the maximum
charging current is 5A. For a lithium battery, if it is impossible to confrm the supported
charging C value, please set the charging current below 1C, for the sake of its (lithium
battery) safety. The reference relation between C value and charging time: charging time
≥60 minutes/ charging C value (e.g. it needs around60-70 minutes to complete charging
with 1C). Due to differences in battery conversion effciency, the time to complete the
charging might be extended.
For safety reasons, a reminder to set the minimum limit value of input voltage will appear
when using DC or battery as power supply. The charger will stop working and report an
error once the voltage is detected to be lower than this value.
In addition to the normal charging function, this product also supports the connection of
a separate battery charging cable and balancing cable to determine the battery voltage.
Charging current: 0.5~10.0A
Max. charging power: 240W/10A
Max discharging power: USB-C 100W/5A
Dimension:72.5x60x26.6mm
Weight: 85g(±10%)
LiHv(4.35V~4.50V)1-6S/ Pb 1-12S/
NiMH 1-16S
