1. When mounting trailer jack, it is best to hook it up to the tow vehicle to
make sure the trailer is secure.
2. Mount jack based on drawing shown above. The Motor orientation
can be selected as shown below.
Note: Select mounting holes as required.(Figure above)
3. Slide A-frame jack through hole on top of A-frame coupler.
4. Line up the three slotted holes on jack mounting plate to the three
holes in the coupler.
5.
With three bolts and nuts (Must be purchased by the user.) secure
jack tightly to the top of the a-frame coupler. (Regularly check to
ensure bolts/nuts are tightened securely.)
ASSEMBLY
overlooking
Rotate 90 (Clockwise)
