Note: Select mounting holes as required.(Figure above)
3.
Slide A-frame jack through hole on top of A-frame coupler.
4.
Line up the three slotted holes on jack mounting plate to the three
holes in the coupler.
5.
With three bolts and nuts (Must be purchased by the user.) secure
jack tightly to the top of the a-frame coupler. (Regularly check to
ensure bolts/nuts are tightened securely.)
1. The input voltage of this product is DC12V, and the 7-star plug is
positive/ground as shown below.
VCC +
overlooking
Rotate 90 (Clockwise)
OPERATION
- 6 -
GND
