when there is any load on the jack.
Note:
1.
The jack is designed for vertical movement of the trailer only.
2.
Rapid and continuous lifting is not recommended to avoid gear
heating and reduce service life.
This product is subject to the provision of European Directive 2012/19/EC. The
symbol showing a crossed-out wheeled bin indicates that the product requires
separate refuse collection in the European Union. This symbol applies to the
product and all accessories marked with this symbol. Products marked as such
may not be discarded with normal domestic waste but must be taken to a
collection point for recycling electrical and electronic devices.
Model
Max. Capacity
Input
Maximum Current
Maximum Power
Mounting Bracket Type
Range
Screw Travel
Drop Leg Travel
The Distance between The
Two Holes in Drop Leg
MODEL AND PARAMETERS
- 3 -
BASIC3500-2-7P
3500 lbs
DC 12V
29±1A
350W
A-Frame Mounting Bracket
9.5-32"
18"
4.5"(4-hole)
1.5"
