Air throughput (m³/h)
Room area
Display
Weight
Subject to technical changes!
7. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for trans-
port damage. In the event of complaints the carrier
must be informed immediately. Later claims will not
be recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating manual before using for the first time.
• With accessories as well as wearing parts and
replacement parts use only original parts. Spare
parts can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The device and the packaging material are not
children's toys! Do not let children play with
plastic bags, films or small parts! There is a dan-
ger of choking or suffocating!
8. Assembly
Place the product on a level, even surface.
Tool required:
• Open-ended spanner, AF 10*
*Not included in the scope of delivery!
8.1 Mounting the handle (1) (Fig. 3)
1. Align the handle (1) with the holes on the housing.
2. Use the M6x35mm (1a) nuts to secure the handle
(1).
8.2 Fitting the drain hose (condensate) (5) (Fig.
5 + 6)
1. Open the flap (dust filter) (2) by pulling.
2. Pull the spring split pins (2a) inwards to remove
the flap (dust filter) (2).
3. You can now open the maintenance flap (collec-
tion bucket) (8).
4. Ensure that the hose is connected to the hose
connection (condensate) (5a) from the inside in
the housing.
22 | GB
1000 m
/h
3
5. Now re-install the maintenance flap (collection
70 - 100 m
2
6. Push the drain hose (condensate) (5) as far as
LCD
45 kg
7. Ensure that the end of the drain hose (conden-
9. Commissioning
• Place the product on a horizontal, level surface be-
• The product must be installed in accordance with
• Use a type H05VV-F 3G 1.5 mm
1. Insert the plug of the mains cable into the socket.
2. The dehumidification value can now be set to be-
3. Once you have set the required value, wait 5 sec-
9.1 Input button functions
1. Switch-on/switch-off button (ON/OFF): You can
2. "Plus/Minus" buttons: Use these two buttons
3. "Mode" button: You can press this several times to
Automatic defrosting
If the ambient temperature is low, the product starts
the defrosting process automatically. In this phase,
the cooling fan operates normally, only the built-in
compressor switches off. The "Automatic defrosting"
icon and the WIND icon illuminate on the display dur-
ing this phase.
www.scheppach.com
bucket) (8) and the flap (dust filter) (2).
possible onto the condensate hose connection
(condensate) (5a).
sate) (5) is in a suitable collection bucket or a
drain before commissioning.
fore using it.
national connection regulations.
the appliance to the socket.
The product confirms this with a signal tone. The
display with control panel (7) now shows the am-
bient humidity.
tween min. 30% and max. 80% using the Plus/
Minus buttons (the dehumidification mode icon
flashes during this process.
onds until the product saves the value. The de-
humidification mode icon now stops flashing and
the building dryer starts. The ambient humidity
display shows the change.
use this button to switch the product on and off.
to set the desired humidity value. Press the Plus
or the Minus button repeatedly until the re-
quired value is reached or press and hold the but-
ton (the values now run smoothly in the respective
direction) and release when the required value is
reached.
set the humidity, the on/off timer in hours and the
wind speed. If you press and hold the button for
10 seconds, you go to the defrosting time setting.
P1: Compressor operating time, adjustable to be-
tween 0 and 60 minutes.
P2: Defrosting time, adjustable to between 8 and
15 minutes.
cable to connect
2
