STEINEL professional True Presence IP Bedienungsanleitung Seite 74

For trouble-free operation of the Bluetooth network:
• Do not interconnect than 100 products.
• Make sure each product is within reach of other pro-
ducts in the Bluetooth network.
LED function
Starting up: The LED flashes white slowly for 10 seconds
Initialisation: The LED lights up blue permanently
Normal mode: LED OFF
Identification: The LED flashes blue slowly
Error: The LED flashes red rapidly
No application available: The lights up in cyan permanently
Test mode, movement: LED rapidly flashes green
Firmware update: The LED flashes cyan rapidly
Make LAN connection with the sensor
• Start web browser.
DHCP is factory-activated.
• Check which IP address the sensor has been given and
use it to open the web interface.
If no DHCP server is available, the sensor is configured as
followed:
– IP address: https://192.168.1.200
– Sub-network mask: 192.168.1.0/24
– In this case, the computer must be set to the same
subnet (192.168.1.0/24).
Instead of using the IP address, the sensor can also be
accessed via the host name. The standard host name is:
„steinel_" + the last 6 characters of the MAC address.
Example:
MAC address is CC:BD:35:12:34:56, the host name is:
steinel_123456
You will find the relevant MAC address on the load module.
– 74 –
