3.4
INSTALL THE MULCH PLUG
Figure F
1. Open the rear discharge flap and hold it.
2. Remove the collecting bag.
3. Hold the mulch plug by its handle in the orientation
shown in figure and fit it into the discharge chute
4. Close the rear discharge flap.
3.5
SET THE CUTTING HEIGHT
The machine can be set to different cutting heights.
Figure G
1. Pull the cutting height adjustment lever backwards
slightly to relieve the pressure on the locating pin. At
the same time pull the locating pin out.
2. Move the cutting height adjustment lever backwards
to raise the height or move it towards to decrease
the height.
3. Align the upper and lower holes, then insert the
locating pin .
3.6
INSTALL THE BATTERY PACKS
WARNING
If the battery pack or charger is damaged, replace
the battery pack or the charger.
Stop the machine and wait until the engine stops
before you install or remove the battery pack.
Read, know, and follow the instructions in the
battery and charger manual.
Figure H
1. Open the battery compartment cover.
2. For the battery pack into each battery compartment,
align the ribs on the battery pack with the grooves in
the battery compartment.
3. Push the battery pack into the battery compartment
until the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery compartment cover.
6. After inserting the battery pack, the battery indicator
will turn from grey to green.
NOTE
You can also insert one or two battery packs.
NOTE
When the battery pack is lower than 16%, the battery
indicator will turn red.
English
If the battery pack becomes over-heated, the
temperature indicator will turn red and flash.
3.7
REMOVE THE BATTERY PACKS
Figure H
1. Open the battery compartment cover.
2. For each battery pack, push and hold the battery
release button (21). on the side of the battery
compartment.
3. Remove the battery packs from the machine.
4
OPERATION
Eye protection must be worn when operating this
machine.
It is recommended to wear sturdy, fully enclosed,
safety footwear with good grips when operating this
machine.
4.1
START THE MACHINE
Figure I
1. Press the power switch once. The display will
illuminate.
2. Push aside the mechanical lock trigger (2).
3. Place fingers over the bail (3) and pull it towards the
main handle.
4.2
STOP THE MACHINE
Figure I
1. Release the bail switch to stop the machine.
2. The machine has a standby time of 5 minutes. To
continue operating during this period requires only
engagement of the bail.
3. Within the 5-minute standby time, the machine can
be manually shut down by pressing the power
switch.
Wait until the blade fully stops before you start the
machine again. Do not quickly turn the machine off
and on.
Always remove battery pack after you complete the
work.
5
NOTE
WARNING
NOTE
WARNING
WARNING
