EN
6. Untighten the blade bolt. Recommended tightening
torque: 33 - 37 N.m.
7. Remove the washer, blade, and blade fixed seat.
8. Install the blade fixed seat on the motor shaft with
the R side facing up.
9. Install the new blade to the blade fixed seat.
10. Place the washer onto the hole of the blade.
11. Mount the blade bolt to the motor shaft.
Recommended tightening torque: 33 - 37 N.m.
5.4 STORE THE MACHINE
• Remove the battery pack(s).
• Clean the machine before storage.
• Make sure the motor is not hot when you store the
machine.
• Make sure that the machine does not have loose
or damaged parts. If it is necessary, follow these
instructions:
6 TROUBLESHOOTING
If there is a fault with the machine, the control panel will display a fault code. Please refer to the table for a solution.
English
• Replace the damaged parts.
• Tighten the bolts.
• Speak to a person at an approved service
center.
• Store the machine in a dry area.
• Make sure that children cannot come near the
machine.
5.5 STORAGE
Figure P
1. Remove the grass catcher.
2. Remove the batteries.
3. Line up the handle knobs in the top hole on the
brackets.
4. Push the bolt into the slot and rotate clockwise to
fasten it.
5. Do the same operation on the other side.
