EN
1 DESCRIPTION
1.1 PURPOSE
This machine is used for commercial lawn mowing. The
cutting blade should be parallel to the ground. All four
wheels should touch the ground while mowing.
1.2 OVERVIEW
Figure A
Bail switch
1
Headlight
2
Self-propelled drive lever
3
Collecting bag
4
Rear discharge flap
5
Handle adjustment knob
6
Central height adjustment lever
7
Battery compartment cover
8
Mulch plug
9
1.3 OVERVIEW FOR PANEL
Figure B
Power switch
10
Cutting speed switch
11
Drive speed switch
12
Headlight switch
13
Cutting speed indicator
14
Battery indicator
15
Drive speed indicator
16
Security indicator
17
Total running time indicator
18
Headlight indicator
19
2 SAFETY
Make sure that you follow all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
Do not use accessories that are not recommended by
the manufacturer.
Do not put in the battery packs until you finalized the
assembly of all the parts.
WARNING
WARNING
WARNING
English
3.1 UNPACK THE MACHINE
Make sure that you correctly assemble the machine
before use.
• If parts of the machine are damaged, do not use
the machine.
• If parts are missing, do not operate the machine.
• If parts are damaged or missing, contact the
service center.
1. Open the package.
2. Read the documentation provided in the box.
3. Discard cardboard corner from the box.
4. Discard cardboard surrounding the mower from the
box.
5. Remove the grass catcher from the carton.
6. Cut open the rear corners of the carton, nearest the
back of the mower.
7. Roll the mower backwards from the carton through
the flattened carton end.
For your personal safety, do not insert battery before
the tool is assembled completely.
3.2 UNFOLD AND INSTALL THE
HANDLE
Figure D
1. Line up the handle adjustment knob in one of the
three positions on the brackets.
2. Push the bolt into the slot and rotate clockwise to
fasten it.
3. Do the same operation on the other side.
Make sure that the two handle bolts are in the same
position.
3.3 INSTALL THE COLLECTING BAG
Figure E
1. Open the rear discharge flap and hold it open.
2. Remove the mulch plug.
3. Hold the collecting bag by its handle and engage the
hooks on the rear flap mounting rod.
4. Close the rear discharge flap.
4
WARNING
WARNING
WARNING
NOTE
