22 | English
Accessory
Scraper, flexible
Bi-metal segment
serrated blade
TC Riff sanding fin-
ger
TC Riff plunge cut
saw blade
HCS universal joint
cutter
Fitting/changing the accessory (AutoClic)
(see figures A–B)
Remove the accessory if one has already been fitted.
To do so, open the AutoClic lever (1) all the way. The access-
ory/accessory will be ejected.
Place the required accessory (e.g. plunge cut saw
blade (12)) on a level surface so that the depressed centre
is face down (see figure on the graphics page; you should be
able to read the text on the accessory from above).
Turn the accessory to a position which is convenient for the
job at hand. Press the power tool onto the accessory at the
required angle until it audibly engages.
Check that the accessory is seated securely. Accessor-
u
ies that are attached incorrectly or are not securely fixed
in place may come loose during operation, thereby put-
ting you at risk.
Fitting and Adjusting the Depth Stop
The depth stop (15) can be used when working with seg-
ment saw blades.
Remove the accessory if one has already been fitted.
Slide the depth stop (15) over the accessory holder (10)
and onto the collar of the power tool as far as it will go, with
the labelled side facing upwards.
The depth stop is intended for the following cutting depths:
– With segment saw blades ACZ 85 .. with a diameter of
85 mm: Cutting depths 8 mm, 10 mm, 12 mm and
Choosing the Sanding Sheet
Different sanding sheets are available, depending on the material you are working with and the required surface removal rate:
1 609 92A B1B | (19.12.2024)
Material Application
Carpet adhesive, paint Flexible scraping on a soft surface.
residue, silicone Example: Removing silicone joints, carpet adhesive
residue and paint residue
Insulation material, insula- Precise cutting of soft materials;
tion boards, floor panels, example: Cutting insulation boards to size, cutting pro-
impact sound insulation truding insulation material to length so that it is flush with
boards, cardboard, car- the surface
pets, rubber, leather
Wood, paint Sanding of wood or paint in hard-to-reach areas without
sanding paper.
Example: Sanding off paint between window shutter slats,
sanding wooden flooring in corners
Fibreglass, mortar, wood Plunge cuts in extremely abrasive materials;
example: Routing of thin mosaic tiles
Expansion joints, window Cutting soft materials;
putty, insulation materials example: Cutting silicone expansion joints or window
(rock wool) putty
14 mm (information on the depth stop in a larger font size
and without brackets).
– With segment saw blades ACZ 100 .. with a diameter of
100 mm: Cutting depths 14 mm, 16 mm, 18 mm and
20 mm (information on the depth stop in a smaller font
size and in brackets).
Insert the appropriate segment saw blade for the desired
cutting depth. Slide the depth stop (15) from the accessory
holder (10) in the direction of the accessory until you can ro-
tate it freely. Rotate the depth stop (15) so that the desired
cutting depth is above the section of the saw blade that will
be used to saw. Slide the depth stop (15) onto the collar of
the power tool once again as far as it will go.
Remove the depth stop (15) for all other cutting depths and
for working with other accessories. To do this, remove the
accessory and pull the depth stop away from the collar.
Fitting the Auxiliary Handle (accessory)
The low-vibration auxiliary handle (8) enables the tool to be
used safely and more comfortably.
Screw the auxiliary handle into the thread (9) on the left or
right of the machine head depending on how you are work-
ing.
Do not continue to use the power tool if the auxiliary
u
handle is damaged. Do not make any alterations to the
auxiliary handle.
