Temperature control in the medium with PT 1000 temperature sensor
Minimum depth of immersion sensor
Measuring accuracy
Setting accuracy
Resolution - display
Standard tolerance
Control system
Operating voltage
Nominal voltage
Design frequency
Input power max. at 230 and 115 VAC
Input power max. at 230 and 115 VAC
Input power max. at 230 and 115 VAC
Power consumption in stand-by mode
Self-heating of the set-up
plate by max. stirring (RT: 22 °C /
duration: 1 h)
Perm. duration of operation
Perm. ambient temperature
Perm. relative humidity
Protection type acc. to DIN EN 60529
Protection class
16
Technical data
mm 20
K ± 0,2
+ sensor tolerance
DIN IEC 751 class A
K 1
K 0,1
K ± 0,5
PID
VAC 220 - 230
±10%
VAC 120
±10%
VAC 100
±10%
VAC 230 / 50 Hz
VAC 115 / 60 Hz
VAC 100 / 60 Hz
Hz 50 / 60
W 270 HS 4
100 VAC W 270 HS 4
W 1020 HS 7
100 VAC W 1020 HS 7
W 1520 HS 10
100 VAC W 1070 HS 10
W 2,5
K +2
% 100
°C +5...+40
% 80
IP 21
I
Overvoltage category
Contamination level
Operation at a terrestrial altitude
Dimensions (W x D x H) HS 4
HS 7
HS 10
Weight HS 4
HS 7
HS 10
Motor
Speed range (infinitely)
Speed display
Power consumption
Power output
Max. stirring quantity (water) HS 4
HS 7
HS 10
Heating plate
Heating plate-/ Setting up plate dimensions
Heating power (±10%) at 230 and 115 VAC
at 100 VAC
Heating power (±10%) at 230 and 115 VAC
at 100 VAC
Heating power (±10%) at 230 and 115 VAC
at 100 VAC
Surface temperature Room temperature at °C
Temperature fluctuation
Limit of safety temperature (firmly adjusted)
Range of adjustment Hi-Temp
Subject to technical changes!
II
2
m max. 2000
mm 150 x 260 x 105
mm 220 x 330 x 105
mm 300 x 415 x 105
kg 3
kg 5
kg 6
rpm 0/100 - 1500
Scale
W 15
W 1,5
ltr 5
ltr 10
ltr 15
mm 120 x 120 HS 4
mm 200 x 200 HS 7
mm 280 x 280 HS 10
W 250 HS 4
W 250 HS 4
W 1000 HS 7
W 1000 HS 7
W 1500 HS 10
W 1050 HS 10
500
K ± 5
°C 550
°C 0 - 500
