Setting operating mode
Operating the device in mode A, B or C
The mode selected will be shown on the display (J).
Operating mode A
The target temperature selected will be reset to 0 °C if the device is swit-
ched off or disconnected from the power supply. The heating function
will be set to OFF when the device is powered on.
• Heating is only possible in connection with the temperature sensor
PT 1000.
• Setting the HI TEMP-function is possible.
Factory setting: mode A
Operating mode B
All settings will be stored if the device is switched off or disconnected
from the power supply.
• Heating is possible without the temperature sensor PT 1000. The target
temperature selected corresponds to the heating plate temperature.
• Setting the HI TEMP - function is not possible.
Operating mode C
All settings will be stored if the device is switched off or disconnected
from the power supply.
Functions see mode B.
The settings are preset and not changeable.
For changing the settings select the operating mode A or B.
Changing the operating mode
The operating modes can only be selected successively!
• Put device switch (A) in the OFF position
• Press and hold the rotating knob (B)
• Put device switch (A) in the ON position
• Release the rotating knob (B) when fig. 1 is indicated on the display
• Sequence A-B-C-A-B-C-A etc.
Safe temperature limit
The temperature set for the heating plate (maximum 500 °C) will be
limited by a preset safe temperature limiter. The heating function will be
set to OFF if this temperature limit is reached.
Warning! The safety temperature limit must always be
set at least 25 °C lower than the fire point of the media
to be processed!
Setting HI TEMP
HI TEMP limits the adjustable target temperature .
After switching on the device the display indicates the value 500 °C
instead of the actual temperature (K) and the blinking signal SET next to
the symbol HI TEMP (N).
The target temperature max. (L) can be set in the range of 0 - 500 °C by
turning the rotating knob TEMP as long as the signal SET blinks.
Warranty
In accordance with IKA Terms and Conditions of Sale, the warranty peri-
od is 24 months. For claims under the warranty please contact your local
dealer. You may also send the machine direct to our works, enclosing
the delivery invoice and giving reasons for the claim. You will be liable
for freight costs.
The warranty does not cover wearing parts, nor does it apply to faults
resulting from improper use or insufficient care and maintenance con-
trary to the instructions in this operating manual.
