Control Board
The Control Board offers several features: you can e. g. simply set the starting address.
The main menu is accessed by pressing the Enter-button. Browse through the menu by pressing Up or
Down. Press the Enter-button in order to select the desired menu. You can change the selection by pressing
Up or Down. Confirm every selection by pressing the Enter-button. You can leave every mode by pressing
the Esc-button. The functions provided are described in the following sections.
Default settings shaded.
Main
Sub menu
menu
ADDR
CHAL
SLAV
CNTL
BLAC
SRED
SGRE
SBLU
SRGB
PR. 1
PR. 2
PR. 3
PR. 4
PR. 5
PR. 6
PR. 7
PR. 8
CTRL
MIC
LODA
OTHE
VER
Display
AXXX (1-512)
C006
C015
C060
C063
ON/OFF
MAST
ALON
RXXX
GXXX
BXXX
RED RXXX
GREE GXXX
BLUE BXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
SPED SXXX
FREN FXXX
MAST Sound-controlled Program Run as Master
ALON Sound-controlled Program Run in Stand Alone
M-XX
Mic sensitivity
YES (ENTER)
Restore factory settings
Vx.x
Software version of each IC
25/31
Function
DMX address setting
6 channel mode
15 channel mode
60 channel mode
63 channel mode
Set unit to slave
Automatic Program Run as Master
Automatic Program Run in Stand Alone
Blackout
Dimming red LEDs
Dimming green LEDs
Dimming blue LEDs
Set red LED value
Set green LED value
Set blue LED value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
Set running speed value
Set strobe value
