iC7-Automation Frequency Converters Quick Installation
Installation Guide
1 Instructions
1.1 Safety and Installation Awareness
A quick installation guide and a safetyguide are provided with the drive. Beforestarting installation, read all safetyguidelines and
precautions in the safety guide (136R0243). For details on cyber security, see Security Features in the application guide (136R0283).
Additional resources - including a design guide, an application guide, and a comprehensive installation guide - can be downloaded
at www.danfoss.com/service-and-su
I .2 Required Tools
Lifting aid
Tape measurer
Wrench with extension and 10 mm socket
Torx and slotted screwdrivers (Tl 5, T20, T25, no, T50, SLI, and SL2)
Wlre crimper
Sheet metal punch and/or pliers for cable entry plate
1.3 Verifying the Shipment and the Contents
Make sure that the items supplied and the information on the product labe correspond to the order confirmation. The product
label is found on the top of the drive.
iC7-Automation
WC: IC7-60FA3N05-01A3E20C1„
2
PIN: 136U3748
POWER: 0.37
3
IN: 3x380-500V 50/60Hz
OUT: no-in O.S90Hz1.3/1.zA
4
ENCL: IP201 open Type
Eff. CIS: IE2 - 5.41 %
sccR: IOOkA
5
IC7FA02T516A011
6
MAC: X 1 ,'X2: 20-79-18-5F-47-9F
Illustration 1: Example of a Product Label
Model code
Part number, serial number, and manufacture date
2
(YYWW)
3 Power rating
Input and output voltage, frequency, and current
4
1.4 EMC-compliant Installation
For EMC-compliant installation, refer to the operating or design guide and follow the electrical installation instructions.
Use shielded cables for motor output (unshielded cables within metal conduit are also acceptable), brake, DC, and control wir-
Ing.
Connect the shield to the enclosures at both ends. If the shield connection points have a voltage potential difference, connect a
low impedance equalizing wire parallel to the shielded cable. Otherwise, break the shield connection on one end to prevent
ground current oops.
Ensurethat motor, brake,and DCcablesare asshort as possibleto reduce the interference level from the entire system.
Provide a minimum 200 mm (7.9 in) separation, if possible, between mains input, motor cables, and control cables.
Danfoss A'S @2023.05
pport.
SIN: OGIAB2C3-2027
1.1
Tanb: -25-SO•C
Danfoss A'S
DK-6430 Nordborg
www.dMfoss.
111
MADE IN DENMARK
/ Xo: 20-79-18-5F-47-A3
Guide
5 2D code — accessibleby using a Datamatrix ECC200
compatible barcode reader —containing the model
code, part number, serial number, and manufacture
date
Frame designation
6
7 Compliance code
AN31974005764101-000401
Instructions
/ 136R0242 5
