System Sensor FL0111E-HS Kurzanleitung Zur Installation Seite 3

Figure 7: Sequence (1 to 9) to Mount the Detector on the Bracket
7a
7b
4
0.00
o
7c
6
7
7d
D200-101-01
1
99 mm
41
mm
2
90 mm
5 3
329 mm
8
9
Pipe Hole Configuration
Figure 8 below shows the pipe holes available on the unit. Each unit
has 2 pipe holes per channel connected together like a T-Piece. If
using a 1 channel unit, holes 3 and 4 do not function. Use Table 1 to
locate the holes required for the installation:
1
CHANNEL 1
CHANNEL 1 (NOT
USED FOR COMMON
5
CHAMBER UNIT)
Table 1: Pipe Holes Used for Each FAAST LT-200 Model
FAAST LT MODEL INLET PIPE HOLE
FL0111E‐HS
1 and / or 2
FL0112E‐HS 1 and / or 2
FL0122E‐HS Channel 1 ‐ 1 and / or 2
Channel 2 – 3 and / or 4
Note 1: Pipe holes not used should be kept sealed.
Note 2: Do NOT glue pipes into the pipe holes.
Table 1a: Maximum Number of Pipe Holes Allowed Per Channel
All figures quoted using highest (level 1) sensitivity
CLASS PIPE LENGTH (M)
C 100
200 (2 x 100)
C 160 (2 x 80) for NF
Using T-Piece
100
B
(80 for NF)
A 80
Pipe Installation
1
3
2 3 4
CHANNEL 2 (ONLY FUNCTION
ON 2 CHANNEL UNITS)
Figure 8: Pipe Holes
CHANNEL 2 (ONLY
FUNCTIONS ON 2
CHANNEL AND COMMON
6
CHAMBER UNITS)
OUTLET PIPE HOLE
5
6
5
6
MAX NO. OF
HOLE SIZES
HOLES /CH
20
(18 for NF)
20 (2 x 10)
For hole diameters
18 (2 x 9) for NF download the latest
version of PipeIQ™
10
(6 for NF)
3
2
I56-6574-006
