The outside of the device should be cleaned periodically to remove contaminants such as dust etc.
1
Disconnect the device from power and allow it to cool before cleaning.
2
Clean the surface with a soft lint-free and moistened cloth. Never use alcohol or solvents as these may
damage the surface. Make sure that no liquids can enter the device.
3
The device must be dry before reapplying power.
There are no serviceable parts inside. Do not open the housing. Do not try to repair the device by yourself as this
may result in damage. Maintenance and service operations are only to be carried out by authorized dealers.
Should you need any spare parts, please use genuine parts. Should you have further questions, please contact
your dealer.
Power supply:
Power consumption:
IP classification:
Protection class:
Power connection:
DMX input:
DMX output:
Status LED:
Material:
Color:
Dimensions:
Weight:
Specifications are subject to change without notice due to product improvements.
Pin connection:
Accessories
No. 59006869
No. 58010372
CLEANING AND MAINTENANCE
TECHNICAL SPECIFICATIONS
100-240 V AC, 50/60 Hz
4 W
IP65
Protection class I
IP T-Con (M)
power cord with safety plug included
1 x 3-pin XLR (M) IP
1 x 3-pin XLR (F) IP
8 x 3-pin XLR (F) IP, galvanically separated
Signal, DMX
Aluminum casting
Black
Length: 22.5 cm
Width: 15.0 cm
Height: 8.5 cm
2.1 kg
TPC-32 Coupler, black
Safety Bond UNV-5 3x600mm up to 5kg silver
17 • EN
