5.2. aScope 4 Cysto specifications
Insertion portion
Bending angle 1 [°]
Insertion cord diameter [Fr / mm, (")]
Distal end diameter [Fr / mm, (")]
Maximum diameter of
insertion portion [Fr / mm, (")]
Working length [mm, (")]
Working channel
Minimum working channel width
[Fr / mm, (")]
Storage
Temperature [°C, (°F)]
3
Relative humidity [%]
Atmospheric pressure [kPa]
Transportation
Temperature [°C, (°F)]
Relative humidity [%]
Atmospheric pressure [kPa]
Optical system
Direction of view [°]
Field of view [°]
Depth of field [mm]
Illumination method
Sterilisation
Method of sterilisation
Operating environment
Temperature [°C, (°F)]
Relative humidity [%]
Atmospheric pressure [kPa]
Altitude [m]
Electrical power
Power requirement
LED power requirement
1. Please be aware that the bending angle can be affected if the insertion cord is not kept straight or
have inserted endoscopic instruments.
2. There is no guarantee that endoscopic instruments selected solely using this minimum working channel
width will be compatible in combination.
3. Storage under higher temperatures may impact shelf life.
10
aScope 4 Cysto
210 ± 15 , min. 120
16.2 ± 0.3 / 5.4 ± 0.1 (0.21 ± 0.004)
16.2 ± 0.3 / 5.4 ± 0.1 (0.21 ± 0.004)
Max 18 / 6.0 (0.24)
390 ± 10 (15.4 ± 0.4)
aScope 4 Cysto
2
Min. 6.6 / 2.2 (0.086)
aScope 4 Cysto
10 – 25 (50 – 77)
10 – 85
50 – 106
aScope 4 Cysto
-10 – 55 (14 – 131)
10 – 95
50 – 106
aScope 4 Cysto
0 (forward pointing)
120 ± 10
3 – 100
LED
aScope 4 Cysto
ETO
aScope 4 Cysto
10 – 40 (50 – 104)
30 – 85
80 – 106
≤ 2000
5 VDC 0.1 A input (from Ambu displaying unit)
18 mA (6.5 VDC) input (from Ambu displaying unit)
