Read these original operating instructions
before using your device for the first time,
follow them accordingly and keep them
for later use or for future owners.
–
Be sure to read the safety instructions no. 5.951-
949.0 prior to the initial startup!
–
Notify the dealer immediately in the case of ship-
ping damage.
–
Check package content when unpacking. For
scope of delivery see illustration 1.
–
At operating elevations of approx. 800 m above
sea level or higher, please contact your dealer to
have the burner setting adjusted to the elevation
and reduced oxygen content.
Table of contents
Environmental protection
Overview
Symbols on the device
Intended use
Safety instructions
Safety devices
Initial startup
Operation
Storage
Transport
Care and service
Troubleshooting guide
Warranty
Accessories and spare parts
EU Declaration of Conformity
Technical data
Environmental protection
The packing materials can be recycled.
Do not dispose of packaging as house-
hold rubbish but place it in recycling.
Old devices contain valuable, recyclable
materials that should be recycled. Batter-
ies, oil and similar materials must not get
into the environment. Therefore, please
dispose of old devices using suitable col-
lection systems.
Electrical and electronic devices often contain compo-
nents which could potentially pose a danger to human
health and the environment if handled or disposed of in-
correctly. However, these components are necessary
for the proper operation of the device. Appliances
marked by this symbol are not allowed to be disposed
of together with the household rubbish.
Please do not release engine oil, fuel oil, diesel and
petrol into the environment Please protect the ground
and dispose of old oil in an environmentally friendly
manner.
Note on content materials (REACH)
Current information on content materials can be found
at:
www.kaercher.de/REACH
12
Figure 1
1
2
3
4
5
6
7
8
9
10 Fuel sieve
11 Safety lever
12 Power supply cable
EN
1
13 Trigger
EN
1
14 Safety latch of the hand spray gun
EN
1
15 EASY!Force trigger gun
EN
2
16 Filling hole for fuel
EN
2
17 Control panel
EN
2
18 Trigger gun storage compartment
EN
2
19 Step recess
20 Handle bar
EN
3
21 Type plate
EN
4
22 Cover lock
EN
4
23 Burner
EN
4
24 Storage compartment for spray lance
EN
5
25 Cover
EN
6
26 Pressure/quantity regulator of the pump unit
EN
6
27 Oil tank
EN
6
28 Oil drain screw
29 Fuel filter
EN
7
30 Fastening clip
31 Water shortage safeguard hose
32 Water shortage safeguard
33 Sieve in the water shortage safeguard
34 Fine filter (water)
Figure 2
A
0/OFF =
1
2
3
4
5
6
–
–
– 1
EN
Overview
Device elements
Support for spray lance
Recessed grip (both sides)
Water connection with sieve
Water connection adapter
EASY!Lock high-pressure connection
EASY!Lock high-pressure hose
EASY!Lock spray lance
High-pressure nozzle (stainless steel)
Steering roller with parking brake
Control panel
Power switch
Off
Operating mode: Cold water operation
Operating mode: Hot water operation (e = Eco lev-
el, hot water max. 60°C)
Rotation direction indicator light
Standby mode indicator light
Fuel indicator light
Service indicator light
Colour coding
Control elements for the cleaning process are yel-
low.
Control elements for maintenance and servicing
are light gray.
Symbols on the device
High-pressure jets can be dangerous if
used improperly. The jet may not be di-
rected at persons, animals, live electrical
equipment or at the appliance itself.
