1.18.11 Inputs, Outputs and Sensors configuration
Inputs:
The system allows to set 7 inputs depending on the operations and preferences of the
installation.
Optional outputs:
There 4 additional available outputs to set. These 4 additional outputs are not wired to the
YUTAKI terminal board.
In order to use them it is required accessory (field supplied). Its configuration follow same
constrains as Standard outputs.
PMEN0597 rev.1 - 06/2023
Standard Outputs:
There are 4 available outputs to
set already wired to the terminal
board. There are conditions of setting
depending on the installation.
Auxiliary sensors:
There are 7 available auxiliary sensors
to set.
