9. Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way; take
it to a qualified service person.
10. Do not disassemble charger; take it to a qualified
service person when service or repair is required.
Incorrect reassembly may result in a risk of electric
shock or fire.
11. To reduce risk of electric shock, unplug charger before
attempting any maintenance or cleaning. Turning off
controls will not reduce this risk.
12. The appliance can be used by children aged from 16
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
13. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
14. Do not recharge non-rechargeable batteries.
15. Never attempt to connect two chargers together.
16. Have your charger serviced by a qualified repair person
using only identical replacement parts. This will ensure
that the safety of the charger is maintained.
17. For the location of the nearest Snap-on repair center,
please call Snap-on customer service at 1-877-762-
7664.
18. To reduce risk of battery explosion, follow these
instructions and those marked on the battery.
19. Never smoke or allow an open spark or flame in the
vicinity of the battery or engine.
20. Never charge a frozen battery.
21. Do not operate charger in a closed-in area or restrict
ventilation in any way.
22. Do not use an extension cord unless absolutely
necessary. If an extension cord must be used, make
sure that the:
— Pins on the plug of the extension cord are the
same number, size and shape of those of the plug
on the charger,
— Extension cord is properly wired and in good
electrical condition, and
— Wire size is large enough for AC ampere rating of
charger as follows
100-120 Volt
Charger
Cord Length (feet)
25
50
100
220-240 Volt
Charger
Cord Length
(meters)
50
75
Recommended Extension Cord Length
ZCTGRS8806CE Rev. A
Wire Size (AWG)
18
18
18
Wire Size (mm)
0.75
1.0
8
SAVE THESE
INSTRUCTIONS
Functional Description
B A C
Figure 1: CTGRS8806/CTGRS8825
A – Collet
B – Collet Nut
C – Spindle Lock (on the side not shown)
D – On/Off Switch
E – Fuel Gauge
F – Motor Intake Filter Screen
G – Release Button
H – Battery Pack
Specifications
Motor Voltage ........................................18.0 VDC
Maximum Wheel/Bit Diameter ...............................
CTGRS8806, grinding . ........ 2-5/32" (54.8 mm)
CTGRS8806, polishing ........ 3-5/32" (80.2 mm)
CTGRS8825, grinding only............ 2" (50.8 mm)
Rated Speed ..........................................................
CTGRS8806 ....................................... 6000 RPM
CTGRS8825 ..................................... 25000 RPM
Weight with Battery Pack ......................................
CTGRS8806 ............................... 4.9 lbs. (2.2 kg)
CTGRS8825 ............................... 4.6 lbs. (2.1 kg)
Length ..................................................................
CTGRS8806 ............................11.4" (290.0 mm)
CTGRS8825 ............................11.4" (290.0 mm)
Operating Temperature
CTGRS8806/CTGRS8825 ...................................
............................... -4°F(-20°C) to 140°F(60°C)
Storage Temperature
CTGRS8806/CTGRS8825 ...................................
............................... -4°F(-20°C) to 140°F(60°C)
Noise* (Tested in accordance with EN 60745)
CTGRS8806 Sound Pressure Level (A) ...81.6 dB
CTGRS8806 Uncertainty, K .......................3.0 dB
CTGRS8806 Sound Power Level (A) .......92.6 dB
CTGRS8806 Uncertainty, K .......................3.0 dB
D F
G E H
