ULTIMATE SPEED UMAP 12000 C4 Originalbetriebsanleitung Seite 17

Step
2. First connect
the red clip (A)
to the positive
pole of the
vehicle battery
and then
connect the
black battery
clip (B) to the
negative pole
(see Fig. 1).
3. Starting up the
vehicle.
1
lead from the portable jump starter with power bank
10
30 seconds and disconnect firstly the black battery clip and then
the red clip from the battery poles. Otherwise, it could result in
dangerous situations! Leave the vehicle engine running.
LEDs
The red Error LED
lights up
continuously, a short
alarm signal sounds.
The red Error LED
lights up
continuously, an
alarm signal sounds
continuously.
The red Error LED
lights up
continuously, an
alarm signal sounds
continuously,
followed by two
short alarm signals.
The green Start LED
and the red
12
Error LED flash
13
alternately. After
1–2 seconds only
the green LED
12
lights up.
B
2.
As soon as the vehicle starts, remove the jump
GB/IE/NI/CY/MT
Meaning / Error
The temperature
13
is too high,
possibly due to
several jump start
attempts.
Battery clips (A)
13
and (B) are the
wrong way round.
A short circuit has
occurred or the
battery is leaking.
13
The connection is
correct.
A
1.
Solution
Disconnect
the black
battery clip
(B) first and
then the red
battery clip
(A) from
the battery
poles. Start
again from
step 1.
Carry on with
step 3...
within
2
17
