SOMFY Dexxo Compact RTS Installationsanleitung Seite 16

EN
12 - DIAGNOSTICS
Indicator light A Meaning
The parameters menu
does not light up is locked.
pressed.
Indicator light B Meaning
Motor waiting for auto-
2
programming
Cell fault
3
Motor thermal
5
protection device
Motor current
6
measuring circuit fault
or sensor fault
Maximum power
7
delivered by the motor
reached during the
auto-programming
phase
13 - TECHNICAL DATA
GENERAL SPECIFICATIONS
Power supply
Standby
Max. power
consumption
Operation
Max. tensile force
Use
Maximum speed
Programming interface
Climatic operating conditions
End limits
Electrical insulation
Integrated lighting
Radio frequency
Number of storable channels
CONNECTIONS
Type
Safety input
Compatibility
Wired control input
Orange light output
Accessories supply output
Offset aerial input
Backup battery
input Battery life
Recharging time
7
Solution?
menu".
Solution?
Start auto-programming
Check that no obstacles
prevent the cells from
detecting.
Check the wiring of the cells
or create a bridge between
terminals 1 and 2 if no cells
are installed.
Check the correct alignment of
the cells.
Leave the motor to cool until
the fault disappears.
Switch off the power supply
wait a few minutes then
reconnect the power supply.
Perform an auto-programming
contact Somfy technical
support.
Product has reached
operating limit.
230 V - 50 Hz
4 W
120 W
600 N
semi-intensive
14 cm/s
2 buttons - 2 indicator lights
- 20°C / + 60°C - dry interior IP 20
Mechanical stop when opening
closing position
LED
433.42 MHz
< 10 mW
32
TX/RX photoelectric cells
V - 15 W
24 V - 500 mA max
(part no. 2400472)
24 hours; 5 to 10 cycles depending
on the door
72 hours
OPERATION
Forced operating mode
Timed lighting (after movement)
Orange light warning
When closing
Security entry
Before opening
operation
(ADMAP)
Integrated obstacle detection
Operation in the event of obstacle
detection
Gradual starting
Opening speed
Closing speed
Docking speed when closing
13.1 Dimensions
171 mini 140
63,7
DEXXO COMPACT RTS
2 sec. automatic if light connected
Total reopening
With
Total reopening
(50 cm)
Longueur hors tout : 3154,6
Course utile : 2555
Fixation : 2981,7
Rail : 2900
269,7
Longueur hors tout : 3127,6
Rail : 2900
173
©
Copyright 2015 SOMFY ACTIVITES SA. All rights reserved.
173
113,5
86,5
